10mm 1 Cm MIni 5/10/20/30/50kg Micro Load Cell Tension Compression Force Sensor for Weight Pressure Column Robotic Touch Sense

TechnicalParameter

Capacity

0-50KG

Rated Output

1.0-2.0mV/V

Zero Balance

±2%F.S.

Non-Linearity

0.5%F.S.

Hysteresis

0.5%F.S.

Repeatability

0.3%F.S.

Creep(30min)

0.1%F.S.

Temp Effecton Output

0.5%F.S./10°C

Temp EffectonZero

0.5%F.S./10°C

Responsefrequency

10kHz

Material

Stainless steel

Impedance

350/500Ω

Insulation

≥5000MQ/100VDC

Operating Temp Range

5-10v

Operating Temp Range

-20-80°C

Safe Overload

120%

Maximum Overload

200%

Cable ultimate pull

10kg
